| Colour/Finish/Material | Pressed steel case with white powder coat finish |
|---|---|
| Controls | On-board controls |
| Heat Output (kW) | 3 |
| Heat selection | Off / Half / Full Heat |
| Heat source | Electricity |
| Installation | Designed for installation into plaster or suspended celings. |
| IP Rating | IP21 |
| Location of heat output | Downwards, out of grille |
| Fan type | 0.00 |
| Noise level (dB) | 51(dB(A)) |
|---|---|
| Warranty | 12 months |
| Product model number | AC3N |
| EAN | 5011139018250 |
| Height | 200.00 (mm) |
| Depth | 135.00(mm) |
| Width | 605.00(mm) |
| Weight | 5.10 (kg) |
| Safety cutout | 2x manual reset cut-outs |
| Mounting Height | Recommended 1.8—2.3 m |
|---|---|
| Construction | Pressed stainless steel case with powder coat finish |
| Accessories | Yes |
| Cable Exit point | Top Centre |
| Cable Size | Supplied by Installer |
| Connection | Installer supplied cable to a permanent connection to an adjacent double-pole switch or conduit connection. |
| Electric supply | ~230/240 |
| Element type | Wire stitched |
